CONVERSIONS
BURNER ARRANGEMENT ON THE HOT PLATE
TABLE
FIG. 15
BURNERS
GAS
NORMAL
PRESSURE
(kPa)
INJECTOR
DIAMETER
(1/100 mm)
N O M I N A L
HEAT
INPUT (MJ/h)
MAX.
BY PASS
N°
DESCRIPTION
1/100 mm
1 ULTRA RAPID
PROPANE
NATURAL
2.75
1.00
94
176
14.5
11.4
85
1/2
2
RAPID
PROPANE
NATURAL
2.75
1.00
91
155
12.0
10.4
45
1/4
3
SEMIRAPID
RIGHT FRONT
AND LEFT BACK
PROPANE
NATURAL
2.75
1.00
70
120
7.1
6.2
35
1/4
4
AUXILIARY
PROPANE
NATURAL
2.75
1.00
53
90
4.1
3.5
32
1/4
