8
Settings
Assembly and removal of the armrest
Assembly:
• Simultaneously connect the front and rear in the
attacks (1).
• Push the armrest until you hear the “click” of the
button inside the front bracket (2).
Removal
• Press the spring (1).
• Slowly push the arm out from the attacks of the
wheelchair at the same time pulling the front and the
rear part (2).
2
2
1
1
1
ARM RELEASE
PIN DETAIL
