Blastrac BMG-780PRO - Centre Pulley

13
Service manual BMG-780PRO
13/57
info@blastrac.eu
Centre pulley BG007867
Item Part number Description Remarks Qty.
108 BG007812 Sprocket 1
109 E03703 V-seal 1
110 BG007806-1 Pulley 1
111 E01490 Bearing 1
112 E03993 Retaining ring for bore Ø90 DIN 472 1
113 BE0126 Retaining ring for shaft Ø50 DIN 471 1
