18
Service manual BMG-780PRO
18/57
info@blastrac.eu
Upper tensioner BG005860
Item Part number Description Remarks Qty.
136 BE0074 Retaining ring for shaft Ø20 DIN 471 1
137 222-2245 Bearing 2
138 BG005830 Axle for tensioner 1
139 BG005831 Tension plate 1
140 BE0130 M10x25 countersunk screw DIN 7991 1
141
142
