Service manual BMG-780PRO
7/57
info@blastrac.eu
Item Part number Description Remarks Qty.
35 BG005847 Protection cap 1
36 BG11924 Upper belt 1
37 BG11899-1/BL Motor 230V/480V 1
38 BE0654 M8x16 set screw DIN 916 4
39 BG007808_2 Coupling upper part 1
40 BE0656 M14x140 hexagon socket head bolt DIN 912 3
41 BG007810 Flange motor seat 1
42 BG007811 Motor seat 1
43 BG005844 Coupling plastic star 1
44 BG11829 V-seal 1
45 BE0635 M8x110 hexagon socket head bolt DIN 912 6
46 BG007808_1 Coupling under part 1
47 BE0188 M6x25 hexagon socket head bolt DIN 912 1
48 BG007839-2 Protection cover 1
49 BE0655 M6x12 hexagon shoulder screw 4
50 E06281 Water T-coupling 1
51 E06278 Waterhose 2,0m
52 E06276 Pipe clamp 2
53 E06897 Slide strip 3,0m
54 E06293 Nut for knee coupling 2
55 E06280 Water knee coupling 2
56 E04551 Plastic cap 1
57 BG007849 Brush for floating shroud 1
58 BG007855 Floating shroud 1
59
