3
INSTALLATION
Installing a Blaupunkt TV Wall Mount is as easy as putting up a shelf. Easy to
follow installation instructions are included with each product.
Most Blaupunkt TV brackets come pre-assembled so installation is simple.
Use the wall plate as a template to mark 4 drill holes
on the wall.
Use a spirit level to ensure the holes are level and in
the required position for your TV. Drill holes of 10mm
diameter and 50mm depth and firmly insert 4 plastic
anchors.
Step 1:
Wall
Step-1
Step 3:
Cover the wall plate with the covers provided.
Step-3
B
1 - Solid Wall installation
Step 2:
Fix the wall plate to the wall using 4 self tap
screws. Ensure the screws are firmly tightened.
Step-2
A
Wall
