No
I Symbol I Function
1.
RES
(RESET)
2.
<!>
(ON/OFF)
SRC
3.
t.!J
4. OPEN I
J../T
5.
-VOL+
SEL
6.
IR
Operations & Controls
Press with a pointed object (such as a ballpoint pen)
to
reset
the
unit
to
its factory settings.
Power On/Off
When the unit
is
turned off, press to turn the unit on.
When the unit
is
turned on, press & to turn the unit off.
Mode Selection
During unit operation, press repeatedly to select the desired mode
for operation.
Bluetooth Mode
Press to pick up
an
incoming call.
Press to detach the front panel from the main unit for inserting
an
SD
card and micro
SO
card (for GPS navigation). The detachable front
panel is also for anti-theft security purposes.
When the TFT screen
is
stored
in
its compartment, press to open
the TFT screen.
When the TFT screen is open, press repeatedly to adjust the angle
for viewing.
When the TFT screen is open, press
& hold shortly to store
the TFT screen to its compartment.
Volume Control
Rotate to adjust the sound output level.
Function Selector
During unit operation, press repeatedly to move to the following
audio
& visual control modes:
- VOL (volume control)
At VOL control mode, rotate SEL to adjust sound output level
- DSP (bass
& treble control)
At DSP control mode, rotate SEL and press
~
~1
I
1~
~
to adjust
output
on
bass and treble
- SOUND (balance
& fader control)
At SOUND control mode, rotate SEL and press
~
~1
I
1~
~
to
adjust balance between left & right speakers
as
well
as
output
level of front
& rear speakers
- DISPLAY (brightness, chroma, contrast
& sharpness control)
At DISPLAY control mode, press
~
~1
I
1~
~
to shift control
through BRIGHT, CHROMA, CONTRAST
& SHARP. When the
desired mode is displayed, rotate SEL to adjust the setting. (Note:
DISPLAY control not available under radio
& Bluetooth operation
mode)
Remote control sensor (for signal reception from remote handset).
[
4]
