ENGLISH
11
CAUTION: LISTENING AT A HIGH VOLUME OVER A LONG PERIOD IS NOT GOOD FOR YOUR EARS.
SPECIFICATIONS
GENERAL
Power Requirement …………………… AC 230V~50Hz
DC 9V UM-2”C” x 6pcs
Power consumption ……………………… 14 Watts
Standby power consumption …………… ＜0.5 Watts
Dimensions……………………………… 400(D) x 180(W) x 150 (H) mm
Operation temperature………………… + 5°C – + 35° C
Weight: 2,02 Kg
RECEIVER SECTION
Receiving Bands ………………………… FM
Frequency Range ………………………… FM 87.5 – 108 MHz
Bluetooth version ……………………… V3.0
USB playback …………………………… Up to 32GB max
COMPACT DISC SECTION
Optical Pickup…………………………… 3-Beam Laser
Frequency Response …………………… 100Hz – 16KHz
AUDIO SECTION
Power output …………………………… 1.8W x2 RMS
ACCESSORIES
Instruction Booklet ……………………… 1
AC Cord ………………………………… 1
Warranty card …………………………… 1
Note:
Specifications are subject to change for continuous improvement, we reserve the rights to
modification without prior notice.
Trouble shooting
a. The display cannot light on.
Answer: Please check if the AC/DC was connected properly.
Please repress the standby power button.
Please contact local service centre for further information.
b. The FM reception is not good.
Answer: Please try to full extent the telescope antenna and adjust the direction of antenna.
Please try to move the unit to another location or next window.
c. The unit cannot play CD disc or intermittent sound.
Answer: Please check if the CD disc was loaded in a correct direction.
Please check the unit was switched to CD mode.
Please check the CD disc face if there have any scratch on it, and try another CD disc.
d. The sound intermittent in Bluetooth playback mode.
Answer: please try to put the Bluetooth device more close to the speaker.
e. There is no sound output.
Answer: Please try to adjust he volume knob.
Please check the battery power, the volume will become small when the battery power
is too low.
Please contact local service centre for support.
BB20BT
