Charging contact
points
Universal wheel
Side brush
Battery cover
Rolling brush
Rolling brush
cover
Anti-drop sensor
Driving wheel
PRODUCT INTRODUCTION
Side brush
• Clean it regularly
• Replace the side brush every 3-6 months to ensure the best cleaning result
Installation
Make the left side-brush (L) and the right-side brush (R) correspond
to L and R on the bottom casing, keep pressing L and R and the side
brushes. They are installed when you hear a “click” sound.
Maintenance
1. Turn the machine over and pull the side brush out and upwards.
2. Remove hair and dirt and reassemble the side brush.
3. Make the left-side brush (L) and the right-side brush (R)
correspond to L and R on the bottom casing, press L and R to
reinstall them.
L
(left side brush)
R
(right side brush)
R L
R
L
