Sumended
Installation
.
l
Make sure that the unit
does not hinder the
movement of torsion bar
spring or other parts of the
trunk lid.
l
Confirm Anti-Vibration
Switches on both the left
and right sides are set to
position
“H”.
l
Attach bracket
(L)
and
bracket (R) using the
hexagonal bolts
(M5
x 8).
0
l
Determine the mounting location and
drill four mounting holes.
3.6 mm Diameter
0
l
Attach the CD changer with the
tapping screws (M5 x 12).
.
Installation of the Controller
Peel off the removable seal on the back of
the controller unit and install it in a location
that will not obstruct driving.
To Next Page
