Blaupunkt IP 240 - Device Panels and Remote Control

IP 240
PANELS
44
1. USB/SD BUTTON
2. FM BUTTON
3. IPOD BUTTON
4. AUDIO BUTTON
5. FAST REWIND BUTTON
6. NEXT BUTTON
7. FAST FORWARD BUTTON
8. STOP BUTTON
9. TONE BUTTON
10. VOLUME- BUTTON
11. VOLUME+ BUTTON
12. PREVIOUS BUTTON
13. STANDBY/SNOOZE BUTTON
14. IPOD INTERFACE
15. PLAY/PAUSE BUTTON
16. DISPLAY SCREEN
17. REMOTE CONTROL SENSOR
18. FM ANTENNA INTERFACE
19. L/R AUDIO INPUT
20. Y,Pr/Pb COMPONENT
VIDEO OUTPUT
21. USB/CARD PORT
22. POWER SUPPLY INPUT
23. POWER ON/OFF SWITCH
