1. Control panel
2. Handle (both side)
3. Castors
4. Deflector
5. Intake grille
6. Air outlet grille
7. Intake grille
8. Power cable
9. Plug fixer
10. Middle condenser drain
11. Condenser drain
12. USB charging slot
Note: USB charging just some mode have this function.
ACCESSORIES
PARTS
PARTS NAME
QUANTITY
Hose inlet
Exhaust hose
Hose outlet
1 set
Window slider kit
1 set
Window slider
without hole
1 set
(May not supply)
Remote control
Battery
1 set
Drainage hose
1 set
(May not supply)
Note: All the illustrations in this manual are for explanatory purposes only. Your appliance
may be slightly different.
