04
Explanation of the operating display and technical parameters
245V
Power light
Charge lamp
Trouble lamp
Current switch button
Charging time
Temperature
245V
Voltage
Power
Rated current
Constant current
Electricity consumption
Time function button
The upstream PE has not
been detected and the
charging cannot be started.
Explapation of the operating display
Technical Parameters
Dimensions (L × W × H)
Weight
Protection Degree ( Control box )
Operating Temperature
260 × 100 × 72.5 mm
1Phase: 2.65 kg
IP65
-30°C to +50°C
1
Model: P1PM2T2 / P1PM2T1 / P1PM2T2C / P1PM2T2BS / P1PM2T1BS
PE Detection
(Earthing Detection)
