8500 Ventilator
Training Manual
12
Insp
Flow
Insp
TIME
Support
Pressure
Press
Limit
Rate Alm
Lo / Hi
Vol Alm
Lo / Hi
Press Alm
Lo / Hi
Adult 30L 1.5 10 50 5 / 25 4 / 10 4 / 55
Paed 20L 1.5 10 40 10 / 35 1 / 6 4 / 45
Insp
Flow
Ventilation
Pressure
Rate Press Alm
Lo / Hi
Adult 30L 30 12 4 / 50
Paed 20L 20 20 4 / 40
Spontaneous with Pressure Support Defaults at start up
Pressure Control Ventilation Defaults at start up
Default for all Modes is “PEEP off” in PCV the maximum PEEP available will be limited to
6 cmH
2
O.
If PEEP is set, the default “PEEP Alarm” will be ± 50 % in the range 0 to 30 cmH
2
O
The Rate or BPM alarm is to be the set value ± 50 % or in SIMV mode Lo 10 hi 20 BPM.
