Blease Test Procedure
Title: 8500 Adjustment & Calibration Document No:129AC000 Sheet 2 of 12
BLEASE QUALITY DOCUMENT
BQD 083.V2
25/5/94
4.1 Test Apparatus
4.2 Initial Checks
4.3 Reference Voltage and Electrical Supplies
4.4 BAV Controller PCB
4.5 Display Interface PCB
4.6 Main Pneumatic Regulator Calibration
4.7 Calibration
4.8 Flow Control Set-up
4.9 Zero Offset Connection
4.10 Pressure Sensor Gain
4.11 Delivered TV Calibration
4.12 Hardware Pressure Overload Backup
4.13 Fresh Gas Flow Sensor Calibration
4.14 Saving Data and Printer Check
4.15 O
2
Monitor Calibration
4.16 PEEP Calibration
4.17 Font Panel Calibration Adjustment
4.18 Parameter Checking
4.19 Assembly Completion and burn in
4.1 Test Apparatus
•
Digital Voltmeter to measure the 4v reference supply.
•
Timeter RT-200 Calibration Analyser with following options fitted: RT-201 Control
Module, RT-202 Press Module, RT-203 Flow Module, or another calibrated calibration
analyser with the required functionality.
•
IBM PC (compatible) ANSI terminal emulator running on serial interface. 9600 baud,
8-data bits, 1 start bit and 1 stop bit.
•
Digital storage scope or chart recorder for monitoring drive gas flow waveform.
•
Ventilator programming cable (12600015). For programming and diagnostics through
calibration port.
•
Front Panel programming lead (12600016).
•
Miscellaneous 17mm/22mm pneumatic tubes.
•
O
2
sensor simulator. (68A – 68D)
•
20 ± 1 L compliance. (C20), 5
±
0.25 L compliance
•
20 ± 2 cmH
2
O /L/s resistance. (R20)
