System Wiring
BZA-4190
System Wiring
6CHANNEL MODE
BRIDGED BRIDGED
CH1
CH2
CH3 CH4
CH3
SPEAKER
4~8 OHM
CH1
SPEAKER
4~8 OHM
CH2
SPEAKER
4~8 OHM
CH4
SPEAKER
4~8 OHM
SUB WOOFER
4~8 OHM
SUB WOOFER
4~8 OHM
INDUCTOR LOW PASS FILTER CAPACITOR HIGH PASS FILTER
