Features & Controls
Features & Controls
MAX
MIN
LEVEL
Fig 1.
Remote Bass Level Control : Optional
Remote Bass Boost Control : This control adjusts the Bass Boost gain for the
amplifier's speaker output (0 - +12dB)
12.B+ TERMINAL (BATTERY POSITIVE)
Due to the power requirements of the Amplifier, this connection should
be made directly to the positive(+) terminal of battery. For safety measure,
install an in-line fuse Holder (not included) as close to the battery
positive(+) terminal as possible with an ampere rating not to exceed total
value of fuses in Amp.
13.SPEAKER TERMINAL
7
