10.5.1 Position lifting units on the vehicle
2 - 8 lifting units form a lifting system. The combinations shown are permissible.
◼ Standard construction with 4, 6, 8 lifting
units
◼ Construction with 2 lifting units and
agricultural support
◼ Construction with 3 lifting units and
special support for agriculture and
trailer
10.5.2 Adjust wheel forks to tyre size
DANGER
Risk of death and injury due to incorrect operation
◼ Always set the wheel forks to the correct wheel diameter.
◼ Lock fork arms securely.
◼ Always adjust both fork arms symmetrically.
◼ Adjust the arms so that they just barely fit under the wheels.
◼ Check the secure engagement of the arms.
