Blitz HydroLift Series - Key Components and Features

HydroLift
Construction and function
126746 85
5.2 Wheel fork
Wheel diameter / Rim size
Ø min.
Ø max.
570 mm
1.300 mm
10"
22. 5"
5.3 Transport handle
Position 1:
The rollers are braked automatically.
Position 2:
The lifting unit can be moved.
5.4 Charger
The charger is suitable for lead acid batteries as well as
batteries suitable for deep discharge.
The supply line must be protected on site with 16 A.
Nominal data charger:
Voltage: 100-240 V Frequency: 50/60 Hz Rated power: 300 W Output voltage: 28 V
Required cable cross-sections when using extension cables with 16 A pre-fuse.
Cable length in (m)
7.5
15
30
Cross section in mm²
1.5
2.5
4
2
1
