DMX Channel Values (8 Channel Mode)
Channel Channel Value Does...
1 000 <-> 255 Pan
2 000 <-> 255 Tilt
3
000 <-> 010
011 <-> 255
Dimmer
Closed
Dimming(0<-->100%)
4 000 <-> 255
Red
0-100%
5 000 <-> 255
Green
0-100%
6 000 <-> 255
Blue
0-100%
7
000 <-> 255
Amber
0-100%
8
000 <-> 255
White
0-100%
DMX Channel Values (13 Channel Mode)
Channel Channel Value Does...
1
000 <-> 255 Pan
2 000 <-> 255 Pan Fine
3 000 <-> 255 Tilt
4 000 <-> 255 Tilt Fine
5
000 <-> 010
011 <-> 255
Dimmer/Strobe
Closed
Dimming(0<-->100%)
6 000 <-> 255
Red
0-100%
7 000 <-> 255
Green
0-100%
8 000 <-> 255
Blue
0-100%
9 000 <-> 255
Amber
0-100%
10 000 <-> 255
White
0-100%
11
000 <-> 010
011 <-> 255
Color Macros
No Function
Color Macros (32)
12
000 <-> 009
010 <-> 255
Strobe
No Function
Strobe ( Slow <--> Fast)
13
000 <-> 127
128 <-> 255
Sound Active
No Function
Sound Active
