Blizzard Flurry 5 - DMX Quick Reference (8-Channel Mode); The Flurry 5 Pin-Up Picture; Control Panel

Page 6
Flurry™ 5 User Manual Rev. A (c) 2013 Blizzard Lighting, LLC
DMX Quick Reference (7-Channel Mode)
Channel What It Does
1 Pan
2 Tilt
3 Dimmer
4 Red Intensity
5 Green Intensity
6 Blue Intensity
7 Amber Intensity
8 White Intensity
7*15-watt
5-in-1 LED’s
Control Panel
LED
Readout
Head
Figure 2: The Rear Connections
AC Power
Fuse Cover
110V/220V Switch
DMX In DMX Out
