INSTALLATION
1-2
RATINGS - GAS APPLIANCES - BC14G/AA
Gas Type Gas Input Voltage Phase Amps Motor
Natural Steam - 55,000 BTU/Hr
Hot Air 65 000 BTU/Hr
208Ć240 1 15 1/2HP 208Ć240VAC, 50/60 Hz
Hot Air - 65,000 BTU
/
Hr
Total - 115,000 BTU/Hr
120 1 15 1/2HP 208Ć240VAC, 50/60 Hz
Propane Steam - 48,000 BTU/Hr
Hot Air 65 000 BTU/Hr
208Ć240 1 15 1/2HP 208Ć240VAC, 50/60 Hz
Hot Air - 65,000 BTU
/
Hr
Total - 113,000 BTU/Hr
120 1 15 1/2HP 208Ć240VAC, 50/60 Hz
3/4" FNPT connector for all U.S. and Canadian installations
TABLE 4
RATINGS - GAS APPLIANCES - BC14GDS/AA
Gas Type Gas Input Voltage Phase Amps Motor
Natural 65,000 BTU/Hr
208Ć240 1 15 1/2HP 208Ć240VAC, 50/60 Hz
120 1 15 1/2HP 208Ć240VAC, 50/60 Hz
Propane 65,000 BTU/Hr
208Ć240 1 15 1/2HP 208Ć240VAC, 50/60 Hz
120 1 15 1/2HP 208Ć240VAC, 50/60 Hz
3/4" FNPT connector for all U.S. and Canadian installations
TABLE 5
GAS PRESSURE - BC14G/AA and BC14GDS/AA
Gas
T
Inlet
P
Orifice Size at Sea Level Manifold Pressure
Type Pressure
Hot Air Steam Hot Air Steam
Natural 7-14" W.C. .0531" dia .042" dia 3.5" W.C. 3.5" W.C.
Propane 12-14" W.C. .032" dia .026" dia 10.0" W.C. 10.0" W.C.
TABLE 6
