BC14G
1-3
OVEN LOCATION
Certain minimum clearances must be maintained
between the oven and any combustible or nonĆ
combustible construction. See the following table.
The following clearances are recommended for
servicing.
D Oven body sides - 12" (30cm)
D Oven body back - 12" (30cm)
NOTE: On gas models, routine servicing can usuĆ
ally be accomplished within the limited
movement provided by the gas hose reĆ
straint. If the oven needs to be moved furĆ
ther from the wall, the gas must first be
turned off and disconnected from the oven
before removing the restraint. Reconnect
the restraint after the oven has been reĆ
turned to its normal position.
Left Side Heat Shield
Heat sources should not be near the air vents loĆ
cated on the left hand side of the gas appliance.
Consult the factory for optional protective side heat
shield.
BC14G P/N R9527
Oven
MINIMUM REQUIRED
CLEARANCES
Model
Right Side Left Side Back
BC14G 1"
(25.4mm)
6"
(152.4mm)
6"
(152.4mm)
TABLE 7
