Condenser sponge (for
products equipped with a heat
pump)
It is very important that the lint and fibres
are caught completely by the filters of
your machine which is equipped with
a condenser with heat pump. Failure in
functioning of the filters may cause a drop
in the performance or breakdown of your
machine. Therefore, in addition to the
“Cover Filter” and “Filter Drawer” filtering
phases in your machine, there is also a
“Condenser Sponge” piece for protection
purpose. If the “Cover Filter” and “Filter
Drawer” are functioning appropriately, ,
“the “Condenser Sponge” piece should
be checked every 3 months. Any layer of
accumulated lint on the sponge must be
removed.
C If the lint and fibre collected on the
sponge is sparse and small, you do
not have to clean the sponge.
To clean the condenser sponge;
1 Take out the condenser sponge from
its place.
C Youcanreachthecondenserfilter
after taking out the filter drawer.
C A wire grid can be seen after taking
out the condenser sponge.
2 Clean the sponge and place it properly
back into its place. Put the sponge in
its housing between the wire grid and
plastic frame.
Important:
• Whenplacingthecondensersponge,
make sure that some part or whole of
lint particles among the pores is not
important.
C If the lint and fibres collected in the
drawer is sparse and small, you do
not have to clean the sponge.
6 Place the sponge back into its place.
7 Close the filter unit as to lock the red
button.
8. Place the filter drawer back into its
place and push forward until a click
sound is heard.
Important:
• Dryingwithoutthefilterspongewill
damage your machine!
• Adirtyheatpumpwillcauselonger
drying periods and higher energy
consumption.
• Placethespongeasshownbelow,
without forcing it. Pay attention to seat
the left side of the sponge into the
appropriate housing in the filter drawer
as marked in the picture.
• Donotsqueezethespongetomake
it go into the inner frame as shown in
the picture below.
