Blu External - Ble Tpms Specification

3
BLU, BLE Sensor Specification
Operating Voltage 3V
Operating Humidity 95 % MAX
Operating Current
＜15 mA at DC 3V
Storage Temperature
-40℃ to 85 ℃
Operating Temperature
-20℃ to 85 ℃
Monitored Pressure Range
Passenger: 0 to 92 psi (0 to 640 kPa)
Truck: 0 to 185 psi (0 to 1280 kPa)
Monitored Temperature Range
-20 ℃ to 85 ℃
Operating Frequency 2.4GHz
Transmission Power 4 dBm MAX
Battery Life 3 years (under normal operating condition)
Battery Capacity 130 mAh (CR1632)
Weight 9.5 g ± 0.5 g (including battery)
Optional Voice Dongle Specifications
Operating Voltage 5V
Operating Humidity 95 % MAX
Operating Current
＜900 mA at DC 5V
Storage Temperature
-40℃ to 85 ℃
Operating Temperature
-20℃ to 85 ℃
Sound Pressure (min.) 80dB@30cm
Operating Frequency 2.4GHz
Transmission Power 4 dBm MAX
Weight 10 ± 1 g
3. BLE TPMS Specification
