BLUBERY GSW02A - 4. Assembly Instructions; Wheel and Frame Assembly; Gun Holster and Hose Hook Assembly

11
4. A SSEMBLY I NSTRUCTION
Gun Holster Assembly
Insert gun hook to the groove then
to the end as per instruction.
Frame Assembly
Position handle assembly and main
frame and connect them with
square neck bolt, then fasten with
the knob. Repeat this procedure for
the opposite side.
Wheel Assembly
NOTE: Make sure that there is
enough air in wheel before
assembly.
Install the wheels to the frame by first
pressing its spring loaded pin on wheel
axle, then insert wheel shaft into frame
and align spring loaded pin with hole in
frame until the pin snaps.
1
2
3
