Blue Bird Micro Bird - Heater Hose Clamp Service

MICRO - BIRD
21
HEATER HOSE CLAMP SERVICE
Tighten heater hose clamps after first 1,000 miles and annu-
ally thereafter.
Heater hose clamps are located as indicated in diagram.
25
HEATER
50
UNDERSEAT
HEATER
HEATER
CLAMP
TRIM
CLAMP ACCESS OPENING
WALL
VIEW FROM TOP
TYPICAL CLAMP ORIENTATION
AT HEATER CORE CONNECTION
50
UNDERSEAT
HEATER
50
UNDERSEAT
HEATER
25
HEATER
PIPE THRU FLOOR
TO REAR HEATER
RETURN LINE
PIPE THRU FLOOR UNDER HEATER
PIPE THRU FLOOR
AT W/H FOR REAR HEATER
RETURN LINE
PIPE THRU FLOOR FOR REAR HEATER INSTALLATION
