Blue Seal Evolution GT46 - Gas Specifications Tables

24
- Australia
- New Zealand:
- United Kingdom & EU (CE):
Category: II
2H3P
(20. 37), II
2H3B/P
.(20, 28-30).
Flue Type: A
1.
NOTE:
* Measure burner operating pressure at Operating Pressure Test Point (Lower - Out) on gas
control valve , this is to be carried out with both burners operating at the 'High Flame'
setting. Refer to information in this section for further details.
Main Burner Injectors Ø 3.10mm Ø 1.90mm Ø 1.90mm
Pilot Burner Injectors
0.45 0.30 0.30
Pilot Screw Adjustment Full Out (CCW) 1½ turns out (CCW) 1½ turns out (CCW)
Burner Operating Pressure (*) 0.98 kPa 2.50 kPa 2.50 kPa
Supply Pressure
20 mbar 37 mbar 28 - 30 mbar
Main Burner Injectors Ø 3.10mm Ø 1.90mm
Pilot Burner Injectors
0.62 0.35
Pilot Screw Adjustment Full Out (CCW) 1½ turns out (CCW)
Burner Operating Pressure (*) 0.98 kPa 2.50 kPa
Supply Pressure
1.13 - 2.0 kPa 2.75 - 3.0 kPa
Main Burner Injectors Ø 3.10mm Ø 1.90mm
Pilot Burner Injectors
0.62 0.35
Pilot Screw Adjustment Full Out (CCW) 1½ turns out (CCW)
Burner Operating Pressure (*) 0.98 kPa 2.50 kPa
Supply Pressure
1.13 - 2.0 kPa 2.75 - 3.0 kPa
