7
CONTROL PANEL
Fig. 1
LEGEND
IL) Line button ON/OFF
TR) Regeneration button ( only for models with "D")
LRCK) CHECK led light (blue)
LTV) Tank temperature led light (red)
LC1) SHORT cycle led light (blue)
LC2) MEDIUM cycle led light (blue)
LC1+LC2) LONG cycle led light (blue)
CYCLE) CYCLE selection button
ST) START CYCLE button
CHECK
C
CYCLE
START
IL
TR
LRCK LTV
LC1 LC2
ST
