Procedure
1. Remove the sticker from the front panel.
2. Slide the unit into the installation opening,
which should be created slightly larger than
the unit size. When installing the unit, it should
be slanted backwards (by 6-10mm).
3. Fill up gaps between the cabinet and the
woodwork / support structure with sponge or
foam.
Support & Protection
– Use Iron Support
If the installation opening is not strong enough
to support the airconditioner, iron supports
should be installed externally on the building.
– Use Sunshade Board
Install a sunshade over the unit on the outside
to prevent direct sunlight on it, as well as to
protect it from falling objects.
