TYPHOON VARIABLE SPEED PUMP PARTS BREAKDOWN
PART #
MODEL #
DESCRIPTION
QTY
1 AC 23248 Knobs 4
2 AC 30341 Lid 1
3 AC 30376 Gasket 1
4 AC 30333 Basket 1
5 AC 23345 Strainer Housing 1
6 AC 23558 Diffuser O-Ring 1
7 AC 23493 Diffuser 1
8 AC 23485 Impeller 1
9 AC 23531 Seal Assembly 1
10 AC 23558 O-Ring 1
11 AC 23566 Flange 1
12 AC 23574 Bolt 4
13 AC 82597 Washer 8
14 AC 23582 Cover/ 1
15 N/A Variable Motor 1
16 AC 23590 Bolt 4
17 AC 32832 Adjustor Foot 1
18 AC 23639 Bottom Base 1
19 AC 23469 Screw 2
20 AC 81590 Drain Plug with O-Ring 2
21 AC 81620 Drain Plug with O-Ring 2
22 AC 23388 Nut 4
