PUMP INSTALLATION
1. When connecting plumbing fittings to the pumps threaded ports, it is recommended
that thread seal tape (Teflon tape) be used. If the suction (intake) connection is not
sealed correctly the pump will not prime
properly and will pump only small volumes of water or no water at all.
3. Suction and discharge lines should be independently supported at a point near the
pump to avoid strains being placed on the pump.
4. It is advisable to install a union in both the suction and discharge lines in the event
the pump needs servicing or removal.
5. Before starting the pump for the first time remove the clear lid at the front of the
pump. Fill the pump strainer with water until it is level with the suction port opening.
Replace the lid making sure the lid is tight Hand
tighten only.
6. BONDING: as required by the National Electrical Code Article 680-26 the pump must
be electrically bonded to the pool structure by a solid copper conductor no smaller
than #8 AWG via the external copper bonding lug on the motor.
7. GROUNDING: Permanently ground the pump motor using a conductor of
appropriate size. Connect to the green headed screw provided inside the motor
terminal box.
NOTE
DO NOT CONNECT MOTOR TO THE ELECTRIC POWER SUPPLY UNTIL
IT IS PERMANENTLY GROUNDED.
