9
LED’S
CONTROL PANEL LCD
OPERATING THE PUMP
• ON – This green power LED is on when the pump is powered on
• WARNING – This LED is on if a warning condition exists
• ALARM – This RED LED is on if an alarm condition exists.
LINE 1 – Key icon indicates password protect mode is active. If password protect has
not been enabled no key icon will be displayed
LINE 2 – Displays to current pump speed ( RPM)
LINE 3 – Count down time and Watts
LINE 4 – Current pump status
STARTING THE PUMP:
1. Be sure pump is powered on and the GREEN power LED is on.
2. Select one of the four speed buttons
STOPPING THE PUMP
1. Press the STOP button to stop the pump
SERVICING EQUIPMENT – WARNING
When servicing equipment – filters, heaters, chlorinators, etc.- Switch off the
circuit breaker to the pump BEFORE you start servicing .
10. QUICK CLEAN – Press Quick Clean and the pump will run at a preset speed
and duration then resume current program speed. Used for vacuuming and pool
maintenance
11. TIME OUT – When active – LED on- at the end of a “time out” preset time, the
pump will run a schedule.
12. START/STOP – Press to start or stop the pump. When the LED is on, the pump
is currently running or in a mode to start automatically
13. RESET BUTTON – Press to reset alarm or alert
