Blue Wave NB19909 - Laguna Pool - Parts Diagram

7
LAGUNA - PARTS DIAGRAM (Not to scale)
Contents vary by package and depth. See parts diagram for specic details of what is in your
package. Check all parts and ensure they are present and undamaged before assembly. Images
and objects may differ. Report missing or damaged parts immediately to have them replaced. For
damaged or replacement parts, contact Blue Wave
®
Customer Service at 1-800-759-0977.
1. Pool Liner
5. Vertical Leg Cap
9. Pool Cover
12. Maintenance Kit*
17. Drain Cap16. Repair Patch
2. Horizontal Beam
6. Pin & Grommet Sets
10.1 EZ Clean 100 Cartridge
Filter (1.25” Return Fitting)*
3. Vertical Leg
7. Drain Connector
10.2 EZ Clean 200 Cartridge
Filter (1.5” Return Fitting)*
4. T-tting
8. Water Stop
11.1 A-Frame Ladder for 48”
Pool*
11.2 A-Frame Ladder for 52”
Pool*
15.1 Hose Clamps for 15’ Pool
14. Water Return Fitting for
15’ and 18’ Pools
13. Water Intake Fitting w/
Water Plug
15.2 Hose Clamps for 18’
and 24’ Pools
*NOTE: The Filter System, Ladder, and Maintenance Kits all come with their own separate instruction
manuals.
