Blue-White FLEXFLO A1 Series User Manual

2.0 ENGINEERING SPECIFICATIONS
1
Maximum Working Pressure (Excluding pump tubes)
100 PSI (6.89 bar)
Maximum Fluid Temperature
O O
185 F (85 C)
Maximum Viscosity
5000 centipoise
Maximum Suction Lift
30 ft. of water at sea level (14.7 atm psi)
Ambient Operating Temperature
O O O O
14 F to 125 F (-10 C to 52 C)
Ambient Storage Temperature
O O O O
-40 F to 158 F (-40 C to 70 C)
Operating Voltage
115V60Hz 1 PH (0.6A max.)
220V50Hz 1 PH (0.3A max.)
230V60Hz 1 PH (0.3A max.)
230V50Hz 1 PH (0.3A max.)
240V50Hz 1 PH (0.3A max.)
Power Cord Options
115V60Hz = NEMA 5/15 (USA)
230V60Hz = NEMA 6/15 (USA)
220V50Hz = CEE 7/VII (EU)
240V50Hz = AS 3112 (Australia/New Zealand)
230V50Hz = BS 1363/A (UK)
Motor
Brushless DC, 50W.
Duty Cycle
Continuous
Motor Speed Adjustment Range
2,000:1 (0.5% - 100%) Max rpm = 65 rpm
Enclosure
®
NEMA 4X (IP66), Valox (PBT) & PA12
Maximum Overall Dimensions
7.25” W x 9” H x 10” D (18.5 W x 22.9 H x 25.2 D cm)
Product Weight
6 lb. (2.7 Kg)
Approximate Shipping Weight
13 lb. (5.9 Kg)
Approximate Shipping Dimensions
10.5” W x 13.75” H x 11” D (26.7 W x 35 H x 28 D cm)
Page 5
®
