blueberry PLUS R2 Installation Manual 3.0 16
4. HANDLING
The blueberry PLUS charging station is delivered in a package with the following
dimensions [Hx D x W] and weight:
▪ blueberry PLUS - User Unit: 2220 mm x 840 mm x 1240 mm – 315 Kg
(87.40 in x 33.07 in x 48.82 in – 694.46 lbs)
▪ Power Unit: 1850mm x 850mm x 1650mm– up to 710 Kg
(72.83x33.46x64.96in – up to 1565 lbs)
Both equipment can only be transported vertically, using a forklift, pallet jacket, or
using a crane and the eyebolts in the top of the equipment, as presented below. In this
case, the angle must be 45º for the weight to be evenly distributed between the eyebolts.
WARNING!
Be careful when moving the equipment. Due to its heavy weight, incorrect transportation
may lead to personal injuries or can damage the equipment itself.
