4 Getting Started
11
4.2 Battery
EF401 uses a Lithium-ion rechargeable battery. Install the provided battery before charging the device.
4.2.1 Installing the Battery
1
Slide the battery lock and lift up the battery cover.
2
1
• When removing the battery cover, be careful not to damage your fingernail.
• Do not try to pull the battery cover excessively. It may damage the cover.
2
Insert the battery. Make sure the gold contacts are aligned.
2
1
To Next Page
