SETTING UP INSTRUCTIONS
* The position of drain water pipe would not be too high (≤15ft).Failure
to do so may cause a water backup in the pump resulting in leakage.
5
CONTROL PANEL
1
2
3
T
P
4
5
8
6
7
1. ON/OFF Key
2. UP AND DOWN Key
3. Purging Indicator
4. Defrosting Indicator
5. PURGE Key
6. HUMIDITY AND TIME Display
7. TIME Key
8. Operating Indicator
≤ 5ft1
