Bluerock Tools 40A - Parts List

40A GRINDER/SANDER/POLISHER
9
Parts List
Drawing
No.
Name
qty
Drawing
No.
Name
qty
1
Output Shaft
1
31
Self-tapping screw
2
2
Woodruff key
1
32
Stator
1
3
Front Cap Screw
4
33
Housing
1
4
Dust Cap
1
34
Flat washer
1
5
Front Cover
1
35
Tapping screw
1
6
Bearing
1
36
Switch Push Button
1
7
Gland
1
37
Switch push Lever
1
8
Gland Screw
3
38
Tension disc screw
2
Flat washer
1
39
Cable disc
1
9
Gear (big)
1
40
Switch
1
10
Set Screw
4
41
Tapping screw
3
11
Set Screw
42
Back frame
1
12
Clamp spring for self-locking
1
44
Sheath
1
13
Clamp spring for Output shaft
1
45
Cable
1
14
Quill roller
1
47
Speed-control switch
1
15
Self-locking spring
1
48
Carbon Brush
1
16
Self-locking
1
49
Carbon brush holder
1
17
Head Cap
1
50
Earth wire
18
Bearing Set Screw
1
51
Aluminum Upper Spider
1
19
Clamp spring
1
52
Handle
1
20
Gear (small)
1
53
Belts cover
1
21
Bearing
1
54
Belt main wheel
1
22
Gear Case Spindle
1
55
Aluminum Lower Spider
1
23
Spur Gear (small)
1
56
Spider set screw
4
24
Bearing Retainer
1
56
Spring
25
Bearing
1
57
Screw
1
26
Rotor
1
58
Spindle
3
27
Rotor axis
1
59
Bearing
2
28
Bearing
1
60
Plastic wheel
4
29
Bearing housing
1
61
Clamp spring
2
30
Windshield
1
62
Belt
1
