Reassembly
12. Alternate placing new blades and blade spacers on the shaft in the order they came off
starting with a blade.
13. Replace the spanner nut and tighten with the same method used to remove it.
14. Thoroughly clean the mating surfaces between the bearing housing, bearing, and blade
shaft. Lubricate each of these surfaces with a thin coat of grease.
15. Set the bearing housing on a flat piece of wood with the bearing aligned on top of it. Use
a rubber mallet to seat the bearing in the housing.
16. Carefully hold the blade shaft vertically on a piece of wood and align the bearing with the
end of the shaft. Use a rubber mallet to seat the bearing on the shaft.
