fig.1
Push (Extractor) Bolt
Lever
Alignment Bolt
Bolt
Spring
Handle
Chain
Side Plate
Link Pin
Side Plate
Breaking Tips
Press Plates
RIVET
Tip
2.20 2.90 3.80
Upper Guide
Lower Guide
Large Anvil
Small Anvil
01
Thank you for purchasing a BlueSpot product, you can find further information
on our range at www.bluespot.uk.com. Please ensure that you are using the
product correctly and that all guidance and cautions are followed in accordance
with the instructions. Please retain these instructions for future reference.
General Information
Introduction and Specification
This tool is designed to break various types of chain. The tool is suitable for use with
drive or cam chains ranging from #35 to #630. Supplied with three breaking tips: 2.2,
2.9 and 3.80.
