7.3 Car Charging
Connect the AC200P L to the vehicle's 12V cigarette lighter port via the DC input cable and
car charging cable. The AC200P L can charge at a maximum of 96W, and it'll automatically
stop charging once it's fully charged.
Note: Make sure your vehicle meets the following conditions for charging:
• The vehicle is capable of supplying power.
• The vehicle's engine is running during the charging process.
7.4 Generator Charging
Connect the AC200P L to a generator via the AC charging cable. The AC200P L also
automatically stops charging when it's fully charged.
Attention:
The AC200P L has a low-voltage disconnect function designed to protect your
vehicle's battery during charging. If the input voltage drops below 10.5V, the unit
will automatically stop charging to prevent over-discharging and potential
damage to the battery.
JUST POWER ON 17
