Bluetti AC300 - Page 36

Wall Outlet
AC Input Port(CP1)
DC Charging Port(CP2)
Generator
Solar panel
AC Adapter
Car
Lead-acid Battery
10.2.3 Charging Method 5: Charging via a 12V/24V Lead-acid battery
Connect the AC300+B300 to the lead-acid battery via the DC input cable and
lead-acid battery charging cable. Clamp the positive connector(red) to the positive
battery terminal and negative(black) to the other.
Note: Set "Others" as DC1/DC2 input source to enable lead-acid battery charging.
10.3 Dual Charging
AC300+B300 also support dual charging via AC input and DC1/DC2 input ports
simultaneously.
31
