Note: The AC500 can work with B300K, B300S and B300 expansion batteries
simultaneously. To connect them:
Connecting to A
C200L
Connect up to 2 B300K units for a maximum capacity of 7,577.6 Wh.
Connecting to AC500
Connect up to 6 B300K units for a maximum capacity of 16,588.8Wh.
P150D battery expansion cable
P090D to P150D battery expansion cable
P090D to P150D battery expansion cable
P090A battery expansion cable
AC500 to B300S
AC500 to B300K/B300
B300K/B300 to B300S
B300K to B300
Cable RequiredConnection
EN
JUST POWER ON
12
P090A
P090D to
P150D
P090A
P090A
