Subject to technical modifications without notice. © 2021
10
1. Hold the bottom door while unclipping the
bottom hinge.
2. Hol d the top door while detaching the
top hinges. Simply unclip them if using
the CLIP top hinges or unscrew them if
using COMPACT.
1
2
3
Removing the doors
Using a screwdriver, depress the release
tabs to remove telescopic arms.
If transporting the cabinet to the jobsite, stop
her e. Lift mechanisms can stay inside the
cabinet for easy transport.
4
Removing the telescopic arms
1
2
Removal
