9
Dimensions in millimeters (inch equivalents as noted) © 2021
Release both arms and gently rest the
top door on the loose arms. The tension
will hold the doors up for the next step.
WARNING
Removal
1
Removing the covers
2
Removing the door
Risk of injury fro m spring-loaded arm
▀ Do n ot push arm assembly down or leave in th e down position.
▀ Remove mechanism before installing or removing cabinet.
1
2
Remove left and right cover plates.
