Subject to technical modifications without notice. © 2021
8
Attach the left and right cover plates to each lift mechanism.
Assembly
1. Close and flush doors to cabinet. While
pressing on the bottom of the top door, pull the
bottom door open one inch.
2. Slightly open door and lock the telescop ic
arms into p osition using the levers as shown.
12
Adjust and lock telescopic arms
13
Attach cover caps
Open door
enough to
lock levers.
1 2
