BLUM AVENTOS HF

5
Dimensions in millimeters (inch equivalents as noted) © 2021
22
31
11.4
38
44
R
4
19
‒
21
R4
7. 5
1. 4
min.
90°
– 0. 1
Ø7
1.1
38
X
17
min.
Top door height
NOTE: 3 hinges are
re quir ed for cabinet width
over 1219 mm (48") or 26.5
lb. combined door weight.
Top door
height (TDH)
X
231 to 271
TDH x .5 + 70
272 to 531
TDH x .5 + 47
6
Frame preparation
7
Bottom door planning
Part no.
Telescopic arm mounting plate
175H5B00
Assembly
