Page #10 background image
0
Subject to technical modications
without notice. © 2007
Detaching the telescopic arms
Removal
Remove covers
Risk of injury from spring-loaded arm
Do not push lever arm down or leave in the down position
Remove mechanism before installing or removing cabinet
WARNING
Release both arms and gently rest
the top door on the loose arms.
The tension will hold the doors up
for the next step.
2
1
Warning: Risk of injury
from spring-loaded
telescopic arm!
Maintain control of telescopic
arm while releasing the CLIP
mechanism.
