5
Subject to technical modications
without notice. © 2007
Reveal
B
12.7
Reveal table
6 5 4 3
3 4 5 6
B Bore distance
Part no.
CLIP top hinge
78Z5530T
Mounting plate
75H6000
7
Bottom door hinge planning
8a
NOTE: See page 6 for 5-panel
door mounting specications
Attaching the telescopic arm mounting plates
12.5
+
Overlay
X
TDH
min.
17
32
Top door
height (TDH)
X
3 to 7
TDH x .5 + 70
7 to 53
TDH x .5 + 47
Part no.
75H500.05
Telescopic arm mounting plate
